Kama ProCut 76 Foil
Machine information
KamaProCut models
2012
17 mill.
740 x 1050 mm.
N/A
Maximum sheet size: 760 × 600 mm
Maximum die cutting size: 743 × 585 mm
Minimum sheet size: 279 × 210 mm
Paper: 100 g-m² and above
Board: up to 1,500 g-m² (approx. 1.8 mm)
Plastic materials (PET, PP, PVC): up to 1,500 g-m²
Maximum speed: 5,500 sheets-hour
Maximum cutting pressure: 165 tons
Gripper margin: 10 mm
Machine dimensions: approx. 4.87 × 2.69 m
Weight: approx. 5,500–6,000 kg
Features:
Automatic die cutting
Creasing
Embossing
Hot foil stamping
